concurrently; SAM2000G configurations cannot be saved independently. Once your IP DSLAM
has been configured as desired (including the SAM2000G), settings can be flash uploaded (to
a local file) through a Trivial File Transfer Protocol (TFTP) tool with a GET command and the
following information:
6.1.2.1 Backup
An IP DSLAM backup file records ALL management and port configurations.
6.1.2.2 Template
An IP DSLAM template file records all management and port configurations EXCEPT the
MUM's IP Address.
Configuration files can also be flash downloaded FROM a local file TO an IP DSLAM, simply
replace the GET command with a PUT command. Refer to your TFTP user manual for further
instruction.
6.2 LED Indications
ITEM DATA NEEDED FOR BACKUP EXAMPLE
Host Name DSLAM_IP Address (xxx.xxx.xxx.xxx) 193.166.254.98
Remote Filename NVR_BACKUP.BIN.[superuser password] nvr_backup.bin.Password
Local Filename user preference dslam27_mum13_backup.bin
ITEM DATA NEEDED FOR BACKUP EXAMPLE
Host Name DSLAM_IP Address (xxx.xxx.xxx.xxx) 193.166.254.98
Remote Filename NVR_CFG.BIN.[superuser password] nvr_cfg.bin.Password
Local Filename user preference n2n_dslam12000_template.bin
LED
State Indication Additional Information
Power (PWR) solid green SAM2000G is
operational If the Power LED is not illuminated, it is unlikely
that the SAM2000G-12 is receiving power, in
which case none of the LEDs will be illuminated.
SHDSL Link (Lk) pulsing
green SHDSL connection
is established and
active The SHDSL link is operational and traffic is
flowing.
solid green problematic SHDSL
connection A connection exists but there is indication of a
problem with the SHDSL line.
no
illumination no SHDSL
connection
210-0000026 rev07
