9
English
EN
Connectors and sockets on rear panel External sockets or connectors
1 For ISO male connectors As indicated above
2 REAR OUT L (White socket) Rear left speaker
3 REAR OUT R (Red socket) Rear right speaker
4 FRONT OUT R (Red socket) Front right speaker
5 FRONT OUT L (White socket) Front left speaker
6 VIDEO OUT 1 (Yellow socket) Video input socket of an external display device
7 VIDEO OUT 2 (Yellow socket) Video input socket of an external display device
8 VIDEO IN (Yellow socket) Video output socket of an external player
9 CAMERA IN (Purple socket) Video output socket of an external camera
10 SUB-W OUT (Blue socket) Sub-woofer
11 AV-IN L (White socket) Left audio channel output socket of an external player
12 AV-IN R (Red socket) Right audio channel output socket of an external player
13 REVERSE CAMERA (Purple wire) Reverse camera (B+)
14 PARKING BRAKE (Pink wire) Parking brake (-)
15 OE SWC IR REMOTE IN (Brown wire) OE SWC remote in
16 OE SWC IR REMOTE IN (Black wire)
Ground
17 OE SWC AD LEARN (White wire) OE SWC AD Learn line 1
18 OE SWC AD LEARN (White wire) OE SWC AD Learn line 2
19 OE SWC AD LEARN (Black wire) Ground
20 External Mic (Black connector) External microphone
21 EXTERNAL BOX CONNECTOR
(Black connector)
External navigation box
22 GPS AERIAL (Black connector) GPS smart antenna
23 RADIO ANTENNA (Black connector) Radio antenna
24 Rear Monitor Audio Out 1 (White
connector)
Left audio channel input socket of one rear monitor
25 Rear Monitor Audio Out 1 (Red
connector)
Right audio channel input socket of one rear monitor
26 Rear Monitor Audio Out 2 (White
connector)
Left audio channel input socket of another rear monitor
27 Rear Monitor Audio Out 2 (Red
connector)
Right audio channel input socket of another rear
monitor
Tip
• The pin arrangement for the ISO connectors depends on the type of your vehicle. To avoid damage to the system, connect
properly.
