8 Basic Operation Instructions
Synergy TRU-Balance Power Recline www.quantumrehab.com
Figure 1. Components of the Synergy TRU-Balance Power Recline
4-WAY TOGGLE CONTROLS (OPTIONAL)
Allows the user to control the recline, tilt, seat elevator, and articulating leg rest
actuators (if so equipped).
4-way Button Toggle 4-way Toggle Quad Push-Button Control
ATTENDANT CONTROL
MODULE
Allows an attendant to
control the actuators. Any
action made through the
Attendant Control Module
overrides the toggle actions
made by the user.
REMOVABLE ARMRESTS
Allows the armrests to be
flipped back or removed
whenever necessary.
ARTICULATING LEG
RESTS (ALR)
Maintains correct
knee-to-heel measurements
when user's legs are raised
or lowered.
SWING-AWAY
ARTICULATING
LEG RESTS (ALR)
Maintains correct
knee-to-heel measurements
when user's legs are raised
or lowered
HIGH PIVOT ELEVATING
LEG RESTS (ELR)
Mimics the motion of the
knee during leg elevation.
LEG RESTS (OPTIONAL)
