Swing-away power articulating leg rests option – Pride Mobility Mobility Power Chair User Manual
Page 19
Basic Operation Instructions
19
www.quantumrehab.com Synergy TRU-Balance Power Recline
SWING-AWAY POWER ARTICULATING LEG RESTS OPTION
The swing-away power articulating leg rests are operated the same way and have
the same features as the power articulating leg rests but have an added swing-
away feature which enables you to rotate the leg rests to the side before you
transfer onto or off of your power chair.
To rotate the swing-away power articulating leg rests:
1. Push in the release lever. See figure 12.
2. Rotate the leg rest.
Figure 12. The Swing-away Power Articulating Leg Rests Option
RELEASE
LEVER
