Basic Operation Instructions 15
www.quantumrehab.com Synergy TRU-Balance Power Recline
Joystick Operation
1. Press the On/Off key to power on the chair and the controller.
2. Press the Mode key twice to select actuator adjustment mode.
3. Push the joystick to the right to cycle through the available motor functions until
the seat back light is illuminated on the actuator indicator. See figure 8.
4. Push the joystick forward to raise the seatback or backward to recline the
seatback.
5. Press the Mode key again to return to the drive mode.
Figure 8. Actuator Modes
3. To return the leg rest to a lowered position, press Select to cycle through
the left, right, and combined leg rests until the desired leg rest actuator is
illuminated on the actuator indicator on the module, and then press the
down arrow until the leg rest is in a lowered position.
Recline Mode Tilt Mode Elevating Seat Mode
ALR/ELR Mode (both) ALR/ELR Mode (right) ALR/ELR Mode (left)
