12 Basic Operation Instructions
Synergy TRU-Balance Power Recline www.quantumrehab.com
! Recline Function
1. To recline, push the second button.
2. To return to an upright position or a 95° recline
position, push the second button again.
! Tilt Function (Optional)
1. To tilt backward, push the first button.
2. To return to a sitting position or to a 0° tilt position,
push the button again.
Quad Push-Button Control Toggle
Figure 6. Quad
Push-Button
Control Toggle
Operation
! Seat Elevator Function (Optional)
1. To elevate the seat, push the third button.
2. To lower the seat, push the third button again.
! Combined Leg Rest Function (Optional)
1. To elevate both leg rests, push the fourth button.
2. To lower both leg rests, push the fourth button again.
! Independent Leg Rest Function (Optional)
1. To elevate the left leg rest, push the third button.
2. To lower the left leg rest, push the third button again.
3. To elevate the right leg rest, push the fourth button.
4. To lower the right leg rest, push the fourth button again.
1
2
3
4
NOTE: The power elevator option is not available when the independent
leg rest option is selected.
