31
RQT7433
Spec
if
ic
at
ions
SUBWOOFER SECTION
[HT720] [Active\subwoofer\SB-WA720]
[HT692] [Active\subwoofer\SB-WA692]
Type 1 way, 1 speaker system (Bass reflex)
Speaker unit(s) Impedance 4 ≠
Woofer 17 cm (6 3 /
4
z) Cone type
Output sound pressure 80 dB/W (1.0 m)
Frequency range 32 Hz–220 Hz ( j16 dB)
36 Hz–190 Hz ( j10 dB)
Dimensions (W tHtD) 209 k361k463 mm
(8 7 /
32
zk14 7 /
32
zk18 7 /
32
z)
Mass
\U.S.A.\and\Canada] 11.7 kg (25.8 lb.)
\Others] 12.6 kg (27.8 lb.)
SPEAKER SECTION
[Front\speakers\SB-FS720]
Type
2 way, 2 speaker system (Bass reflex)
Speaker unit(s) Impedance 4 ≠
1. Woofer 6.5 cm (2 1 /
2
z) Cone type
2. Tweeter 6 cm (2 3 /
8
z) Ring shaped dome type
Input power (IEC) 70 W (Max)
Output sound pressure 80 dB/W (1.0 m)
Cross over frequency 6 kHz
Frequency range 96 Hz–50 kHz ( j16 dB)
105 Hz–45 kHz ( j10 dB)
Dimensions (W tHtD) 86 k240k114 mm
(3 3 /
8
zk9 7 /
16
zk4 1 /
2
z)
Mass 0.9 kg (1.98 lb.)
[Surround\speakers\SB-FS520]
Type
1 way, 1 speaker system (Bass reflex)
Speaker unit(s) Impedance 4 ≠
Full range 6.5 cm (2 1 / 2
z) Cone type
Input power (IEC) 70 W (Max)
Output sound pressure 80 dB/W (1.0 m)
Frequency range 88 Hz–25 kHz ( j16 dB)
100 Hz–22 kHz ( j10 dB)
Dimensions (W tHtD) 86 k180k112 mm
(3 3 /
8
zk7 3 /
32
zk4 13 /
32
z)
Mass 0.73 kg (1.6 lb.)
[Center\speaker\SB-PC720]
Type
2 way, 3 speaker system (Bass reflex)
Speaker unit(s) Impedance 4 ≠
1. Full range 6.5 cm (2 1 /
2
z) Cone type
2. Full range 6.5 cm (2 1 / 2
z) Cone type
3. Super tweeter Piezo type
Input power (IEC) 260 W § (Max)
Output sound pressure 82 dB/W (1.0 m)
Cross over frequency 10 kHz
Frequency range 88 Hz–25 kHz ( j16 dB)
98 Hz–22 kHz ( j10 dB)
Dimensions (W tHtD) 300 k102k116 mm
(11 13 / 16
zk4 1 / 32
zk4 9 / 16
z)
Mass 1.37 kg (3 lb.)
GENERAL
Power supply
\U.S.A.\and\Canada] AC 120 V, 60 Hz
[Others] AC 110 V/127 V/220–230 V/240 V, 50/60 Hz
Power consumption Main unit 25 W
Subwoofer 340 W
Dimensions (W tHtD) 430 k68k432 mm
(16 15 / 16
zk2 11 / 16
zk17z)
Mass Main unit 4.1 kg (9.0 Ib.)
Operating temperature range r5 to r35 oC (r41 to r95 oF)
Operating humidity range 5 to 90 % RH (no condensation)
§ Rating with low cut filter equipped amplifier
[Note]
1. Specifications are subject to change without notice.
Mass and dimensions are approximate.
2. Total harmonic distortion is measured by the digital spectrum
analyzer.
Power consumption in standby mode
\U.S.A.\and\Canada]
0.4 W
[Others] 0.9 W
