Page 13
13
RQT7708
∫ Attaching the stickers to the speakers
Attach the speaker-cable stickers to make connection easier.
[Note]
≥Never short-circuit positive (i) and negative (j) speaker wires.
Be sure to connect only positive (copper) wires to positive (
i) terminals and negative (silver) wires to negative (j) terminals.
Incorrect connection can damage the speakers.
∫ Preventing the speakers from falling over (Front and surround speakers)
[Note]
Consult a qualified building contractor when attaching the speakers to wall. Improper attachment may result in damage to the wall and speakers.
STEP
3
Connecting speakers with the subwoofer
Speaker cables
≥1a4-m (13-foot) cable
(For Center speaker)
Sheet of speaker-cable
stickers
6
Subwoofer
1
Front (L)
4
Surround (R)
3
Surround (L)
5
Center
1 4 3 5
2
Click!
1
2
3
4
5
Short cables
Long cables
Copper
Silver
Speaker-cable sticker
2
Front (R)
_:
`:
Copper
Silver
∫ Connecting the speakers
4 Black screws
4 Clampers
Screw
Clamper
Approx. 150 mm
(5
15
/
16
q)
String (not included)
Screw (not included)
