36
Setup menus
USER menu
(continued)
Item Setting
No.
Superimposed
No.
Superimposed Description
display display
720 EMBEDDED 0000 OFF
AUD 0001 ON
721 LINE CH 0000 PCM
SEL 0001 AUTO
722 INT SG 0000 OFF
0001 ON
723 DV PB ATT 0000 OFF
0001 ON
729 REC PT 0000 OFF
MUTE 0001 ON
731 REF LEVEL 0000 FS-20
0001 FS-18
0002 FS-12
The underline on the setting item denotes the initial setting.
This selects whether to superimpose the audio data onto the
serial output.
0: Data is not superimposed.
1: Data is superimposed.
This display will not appear unless the AJ-YA455P serial inter-
face board (optional accessory) has been installed.
This selects the audio output for CH1 and CH2.
0: PCM AUDIO is output.
1: PCM AUDIO is output in the –0.43
× to 1 × speed range; in
all other cases, CUE is automatically output.
The PCM AUDIO output CH1 and CH2 signals are output
separately regardless of the position selected for the AUDIO
MONITOR SELECT switch.
This selects whether the internal signal is to be used for the
audio input signal.
0: The internal signal is not selected.
1: The internal signal is selected.
• The internal signal has a frequency of 997 Hz.
• This setting is invalid if the VIDEO INPUT switch
#3 has
been set to DVCPRO/DV.
This selects the audio output level for DV format playback.
0: The audio output level is not attenuated.
1: The audio output level is attenuated (reduced).
For selecting whether to mute the sound at the joins between
recordings during DV or DVCAM cassette playback.
0: The sound is not muted.
1: The sound is muted.
For setting the audio reference level.
0: Full scale, –20 dB
1: Full scale, –18 dB
2: Full scale, –12 dB
