EN-27
EN
7.2 Connect devices
This section describes how to connect
various devices with different connectors and
supplements examples provided in the Quick
Start Guide.
Caution: C Disconnect the mains cord
before connecting devices.
Note: D Different types of connectors may
be used to connect a device to your TV,
depending on availability and your needs.
Blu-ray Disc player
For full high-definition video, connect a HDMI
cable as illustrated:
DVD player
For DVD video, connect a SCART cable as
illustrated:
Satellite receiver
To receive analogue channels via antenna
and digital channels via a satellite receiver,
connect an antenna cable and SCART cable as
illustrated:
HD digital receiver
To receive analogue channels via antenna
and digital channels via a HD digital receiver,
connect two antenna cables and HDMI cable as
illustrated:
Combined DVD recorder and digital
receiver
To receive analogue channels via antenna and
record programs on a combined DVD recorder
and digital receiver, connect two antenna cables
and one SCART cable as illustrated
Separate DVD recorder and receiver
To receive analogue channels via antenna
and record programmes on a separate DVD
recorder and receiver, connect three antenna
cables and one SCART cables as illustrated:
DVD recorder and home theatre system
To receive analogue channels via antenna,
output sound to a home theatre system and
record programmes on a DVD recorder,
connect two antenna cables, one SCART cable
and two digital audio cables as illustrated:
Note: D If using a home theatre or other
audio system, the best synchronisation
between images and sound is achieved
by connecting the audio signal from your
playback device to the TV fi rst. Subsequently,
channel the audio signal to the home
theatre system or audio device via the audio
connectors on the back of the TV.
