1 FRAME GROUND 4 RECEIVE COMMON 7 TRANSMIT B
2 TRANSMIT A 5 — 8 RECEIVE A
3 RECEIVE B 6 TRANSMIT COMMON 9 FRAME GROUND
Signal Signal Signal
CONNECTOR SIGNALS
68
Pin
No.
Pin
No.
1 DCR 4 DTR 7 RTS
2 RD 5 GND 8 CTS
3 TD 6 DSR 9 —
Signal Signal Signal
Pin
No.
Pin
No.
Pin
No.
VIDEO
VIDEO IN BNCX1
REF VIDEO IN BNCX2
VIDEO OUT BNCX3 VIDEO/Y, P B , P R
PB VIDEO OUT BNCX3 VIDEO/Y, P B , P R
VIDEO MONITOR OUT BNCX1
AUDIO
AUIDO IN XLRX2 CH1 CH2
AUDIO OUT XLRX2 CH1 CH2
PB AUDIO OUT XLRX2 CH1 CH2
AUDIO MONITOR OUT XLRX1 CH1/CH2/MIX
TC
TC IN BNCX1 (also serves as REF VIDEO IN)
TC OUT BNCX1 (also serves as VIDEO MONITOR OUT)
DC IN
XLR 4P
REMOTE 9P
EDL 9P
AUDIO IN/OUT REMOTE DC IN
1. GND
2. HOT
3. COLD 1. GND
2.
3.
4. +12V
2
1
3
4
2
3
1
1 5
6 9
EDL
2 1
3
loop-through format with 75-ohm,
automatic termination
Pin
