Printing Area
Fanfold Paper
1st character
Paper perforations
Printing area
Printing area
A
D
B
A
C
Fanfold Paper
A 25.4 mm (1 in.)
B 17.8 mm (0.7 in.)
C 2 mm (0.08 in.)
D 15 mm (0.6 in.)
A. The area near the paper perforations where the print quality may not be optimum.
B. The minimum distance between the sprockets and first printable character. (When the left tractor is
set on the left end and the margin is set to 0.)
C. The area from the top edge of the paper to the top of the first printed character.
D. The area from the bottom edge of the paper where the print quality may not be optimum.
44 Operating Instructions
Appendix
