144
Maintenance
Throttle Cable Adjustment
Always check the throttle for smooth operation
before riding. Periodically check the throttle
freeplay. It should be kept between 1/16″ and
1/8 ″ (1.5mm - 3.2mm) (A). If adjustment is
required, turn the adjustment nut (B) until the
freeplay falls in to the acceptable limit.
Brake Freeplay
Brake Freeplay Specifications
Model Front Rear
Predator 50 .1″ - .39 ″ (2.5-9.9 mm) .15″ - .30″ (3.8-7.6 mm)
Predator 90 .40″ - .80″ (10-20 mm) .40″ - .80″ (10-20 mm)
Sportsman 90 .40″ - .80″ (10-20 mm) .40″ - .80″ (10-20 mm)
A
B
