Maintenance
Toe Alignment
3. Tie an elastic string around the stands, making
sure the string just touches the side surface of the
rear tires on each side of the vehicle and goes
around the stands in front of the vehicle (2).
4. Measure the distance from the string to the rim at
the front and rear of the front rim (3). Rear
measurement should be 1/16″ - 1/8″ (.2 to .3 cm)
more than the front measurement.
NOTE: If you discover improper alignment, see
your Polaris dealer for service.
Camber and Caster
The camber and caster are non-adjustable.
A
C
B
