36 C311M-N (6/06)
DISPLAY DURATION
Display Duration programs the duration the Az/El, Direction, and Zoom labels are displayed on the monitor. The available settings for display
duration include the following:
• Constant: The label is displayed continuously.
• 2 Seconds (default): The label is displayed for 2 seconds after PTZ functions end.
• 5 Seconds: The label is displayed for 5 seconds after PTZ functions end.
• 10 Seconds: The label is displayed for 10 seconds after PTZ functions end.
To program the display duration for the Az/El, Direction, and Zoom labels:
1. Program preset 95 (28). The main menu appears.
2. Position the cursor (>) beside Other.
3. Press the Iris Open button to enter the Other menu.
4. Position the cursor (>) beside Az/El/Direction.
5. Press the Iris Open button to enter the Az/El/Direction menu.
6. Position the cursor (>) beside Disp Duration.
7. Press the Iris Open button. The cursor moves to the right.
8. Move the joystick up or down to view the available selections.
9. SELECT: Press the Iris Open button to make a selection.
CANCEL: Press the Iris Close button to cancel selection.
Proportional pan On
Park time minutes 0
Scan Speed deg/s 25
Pattern Length 1.5 min
Spd Profile
Exit
Other Menu
ACK Alert
Exit
MAIN MENU Az/El/Direction
Set Azimuth Zero
Az/El
Az/El Line
Direction
Direction Line
Zoom
Zoom Line
Disp Duration
Exit
