Pelco ESPRIT ES30PC User Manual
Page 66
66
C311M-N (6/06)
–
234
OFF
ON
OFF
ON
OFF
ON
ON
ON
–
235
ON
ON
OFF
ON
OFF
ON
ON
ON
–
236
OFF
OFF
ON
ON
OFF
ON
ON
ON
–
237
ON
OFF
ON
ON
OFF
ON
ON
ON
–
238
OFF
ON
ON
ON
OFF
ON
ON
ON
–
239
ON
ON
ON
ON
OFF
ON
ON
ON
–
240
OFF
OFF
OFF
OFF
ON
ON
ON
ON
–
241
ON
OFF
OFF
OFF
ON
ON
ON
ON
–
242
OFF
ON
OFF
OFF
ON
ON
ON
ON
–
243
ON
ON
OFF
OFF
ON
ON
ON
ON
–
244
OFF
OFF
ON
OFF
ON
ON
ON
ON
Receiver Address
P-Type
D-Type
Control
Control
Switch Setting
SW2-1
SW2-2
SW2-3
SW2-4
SW2-5
SW2-6
SW2-7
SW2-8
–
245
ON
OFF
ON
OFF
ON
ON
ON
ON
–
246
OFF
ON
ON
OFF
ON
ON
ON
ON
–
247
ON
ON
ON
OFF
ON
ON
ON
ON
–
248
OFF
OFF
OFF
ON
ON
ON
ON
ON
–
249
ON
OFF
OFF
ON
ON
ON
ON
ON
–
250
OFF
ON
OFF
ON
ON
ON
ON
ON
–
251
ON
ON
OFF
ON
ON
ON
ON
ON
–
252
OFF
OFF
ON
ON
ON
ON
ON
ON
–
253
ON
OFF
ON
ON
ON
ON
ON
ON
–
254
OFF
ON
ON
ON
ON
ON
ON
ON
Receiver Address
P-Type
D-Type
Control
Control
Switch Setting
SW2-1
SW2-2
SW2-3
SW2-4
SW2-5
SW2-6
SW2-7
SW2-8
