TECHNICAL SPECIFICATIONS
Applications
Multiple V.35 Sync or Async DCE or DTE devices
sharing one V.35 DCE or DTE link
Capacity
One to Four V.35 Sync or Async DTE or DCE
devices One V.35 DCE or DTE Master Channel
Data Format
Data transparent at all data rates
Data Rates
Up to 2.048Mbps
Timing
Internal: ...... DIP switch selectable
Normal: ...... From Modem
External: ...... Clock provided on any Sub-Channel
Anti-streaming
Automatic:Selectable timeout intervals or disable
Terminal Service Modes
Scanning Mode: ...... Channels are continuously
scanned for activity on a
sequential basis.
Priority Mode: ........ Channels are simultaniously
monitored channel one has
highest access
Sub-Channel Interface
CCITT V.35 female connectors (MR-34)
Master Interface
CCITT V.35 female connector (MR-34 & DB-25)
Front Panel
Indicators: ..... Power, Send Data, Receive Data,
Clock Fallback, Sub-Channel Active,
Sub-Channel Stream
Switches: ...... Enable/Disable each Sub-Channel
Power Source
100-120/200-240 Vac, 50 to 60 Hz, 0.16/0.08
A, Switch Selectable
Environmental
Operating Temp: ....... 32° to 122°F (0° to 50°C)
Relative Humidity: ..... 5 to 90% non-condensing
Altitude: .................. 0 to 10,000 feet
Dimensions
Height: ....... 1.75 inches (4.44 cm)
Width: ....... 17.00 inches (43.18 cm)
Length: ....... 11.00 inches (18.93 cm)
Weight
4.5 lbs (2.1 Kg)
