Equipment Grounding (SW15-1)
Switch SW15-1 provides for grounding interconnection in those systems requiring a
connection between (Frame Ground) and (Signal Ground). Connect ONLY if required.
RTS To CTS Delay (SW16-1,2,3)
If a CTS delay is desired, set SW16-1, 2 and 3 to the required value as indicated below.
SW16-1 SW16-2 SW16-3 Time
ON ON ON No Delay
OFF ON ON 1mS
ON OFF ON 2mS
OFF OFF ON 4mS
ON ON OFF 8mS
OFF ON OFF 16mS
ON OFF OFF 32mS
OFF OFF OFF 64mS
Anti-Streaming (SW18-1,2,3)
The maximum data block size is user selectable via switch SW18- 1, 2 and 3. As shown
below eight block sizes are provided to the user. To disable anti-streaming set SW18-8 to the
OFF position. The maximum block size is normally defined at the time of installation.
SW18-1 SW18-2 SW18-3 CLOCKS
ON ON ON 1024
OFF ON ON 2048
ON OFF ON 4096
OFF OFF ON 16 K
ON ON OFF 64 K
OFF ON OFF 256 K
ON OFF OFF 1 MEG
OFF OFF OFF 2 MEG
