9
LSQT1268 (ENG)
¬ Power supply
1 Connect the AC cable to the AC
adaptor A.
2 Connect the AC cable to the AC
outlet.
3 Connect the AC adaptor to this
unit’s DC input terminal
[DC/C.C.IN 5.0 V].
≥ The power lamp B lights up.
≥ The
AC cable is for use with this unit only.
Do not use it with any other devices.
≥ The unit and the disc heat up during use.
This is not a malfunction.
¬ Inserting/removing a
disc
≥ When inserting or removing the disc,
connect the AC adaptor to the unit.
You cannot insert or remove a disc
unless the unit is powered.
1 Connect this unit to the AC adaptor.
2 Inserting disc
Insert the disc in the disc insertion
slot.
The disc is automatically loaded.
A Recording/playback side
Removing disc
Press the [<] button.
≥ Be careful not to touch the recording/
playback side of the disc when inserting/
removing it.
B A
1
3
2
A
