Protec Protech Compact2 Film Processor SX 2 - Manual (Page 46)

46 COMPACT 2 TM
Spare Parts
®
69a 0190-0-0301 Side plate dev. left w. shafts
70 1190-0-0401 Side plate fix. right
70a 0190-0-0401 Side plate fix. left w. shafts
72 1101-0-3700 Guide bar 2, curved with nose
72a 1101-0-4500 Guide bar 2, curved with nose
73 1190-0-3600 Guide bar straight, short
74 1101-0-0306 PU-roller ground
75 1101-0-0307 Rubber roller
Additional information concerning Compact 2 NDT see on page 57
77a 1190-0-0302 Flat spring 68
77b 1170-0-0304 Flat spring 55
77c 1170-0-0303 Flat spring 36
77d 1101-0-0315 Flat spring 30
77e 1190-0-0303 Flat spring 26
79 1190-0-0310 Drive shaft rack C 2
Additional information concerning Compact 2 NDT see on page 57
80 1101-0-0316 Shaft
81 1101-0-0311 Distance bar
82 1101-0-0303 Gear t = 32, D-hole
83 1101-0-0304 Gear t = 32, R-hole
84 1170-0-0302 Worm wheel
Additional information concerning Compact 2 NDT see on page 57
85 1101-0-0302 Gear t = 16, D-hole
86 1101-0-0305 Bearing bush, white
86a 1101-0-0317 Bearing bush, black
87 1102-0-0401 Bearing w. clearance
88 2014-0-0001 Circlip
90 1190-0-0604 Dryer plate, small
91 1190-0-0603 Dryer plate, large
92 1190-0-0605 Dryer plate, rear
93 1190-0-0609 Side plate D top right
93a 0190-0-0608 Side plate D top left (with shafts)
94 1190-0-0607 Slide for dryer separation
95 1190-0-0606 Side plate W/D bottom right
95a 0190-0-0606 Side plate W/D bottom left (with shafts)
Pos. Order No. Description:
