Top Panel

7

Top Panel Drawing

1. SOURCE button

Press to shift modes among DVD, TV, AUX,

S-VIDEO and PC.

2. MENU button

The same function as the LCD SETUP

button on the remote control.

3. CH / button

Press to select channels forward and

backward. While in TV mode, the same

function as , direction button when in LCD

menu set up.

4. VOL+/- button

Press to decrease or increase the volume.

The same function as , direction button

when in LCD menu set up.

5. PLAY button

Press to start playback under DVD mode.

6. Stop

Press to stop playback, then press the PLAY

button to resume normal playback under DVD

mode.

Press the STOP button twice repeatedly to

stop completely.

7. EJECT button

Press to eject the disc out, while in the DVD

mode.

8. POWER button

Press to access to or exit from the STANDBY

mode.

9. Disc Loading Slot

Used for loading discs in.
