Label Specifications 43
Section 5 : Label Specifications
Important! Test all custom made label stock with the intended printer
before ordering large quantities! Primera will only assume responsibility for
custom label stock ordered from Primera.
Label Width
Liner Width
Distance from
edge of Media
to edge of Label
Width of Opening
Black Mark
Width
Gap Between
Labels
Label Height
Distance from
edge of Media
Label Sensing Methods
Method 1: Label
Gap Sensing
Method 2: Thru-Hole
Sensing
Method 3: Reflective/Black
Mark Sensing
(Black Mark must be printed
on back side of label stock)
Note: See table below for Max and Min values in inches and mm..
