UPM51 PROJECTOR MOUNT

To ensure the correct usage, please read and follow the instructions manual thoroughly. Please store the instructions in a safe place for future reference.








To ensure customer safety, be sure to decide the installation location so that the strength is sufficient to withstand the weight of both the projector

and the mount.

Fully tighten all of the mounting screws as specified in the instructions.

Special techniques are necessary for installation of the panel display mount.

Do not attempt to perform this work by yourself.
Request an installation specialist to install this unit.
Manufacturer assumes absolutely no responsibility for injuries and damages that may occur due to improper installation and handling.

Please remember that if you remove the mount from the wall/ceiling later, you will find the screw holes and anchor bolts for the

mounting unit left on the wall.

All PDR mounts and adapters carry a lifetime warranty against defects in material and workmanship. We are not liable for
improper installation that results in damage to mounts, adapters or presentation equipment.

Mounts by

A division of David Engineering & Mfg. Inc.


















! Simple to adjust no-tools required

!

Low profile 4.8”

! Applications for 1 ½”NPT mounting
! +- 20 deg. Pitch

!

+ -30 deg. yaw

!

360 deg. rotation

! Quick projector removal with exclusive

Bayonet locking system”

Features

Thank you for purchasing the PDR Projector mount with the exclusive “Bayonet locking system”.

Bayonet Locking System

Locking thumb screw

Rotate 360 deg

1

Table of contents
