REFERENCE
Pick up
Wavelength
CD
785 nm
DVD 662 nm
Laser power
CD CLASS 1M
DVD CLASS 1
Audio output (Disc)
Number of channels
(FL, FR, C, SL, SR, SW) 5.1 ch
Audio performance (measurement at: Rec Out terminal)
Frequency response (CD-Audio)
4 Hz to 20 kHz
SPEAKER SECTION
Rating with low-cut fi lter equipped amplifi er.
VK960 Front speakers SB-PF960
Type 3 way, 3 speaker system (Bass refl ex)
Speaker unit(s) Impedance High 3 Ω/Low 6 Ω
1. Super woofer 20 cm Cone type
2. Woofer 12 cm Cone type
3. Tweeter 2.5 cm Titanium Dome type
Input power (IEC) High 110 W (Max)/Low 55 W (Max)
Output sound pressure 88 dB/W (1.0 m)
Cross over frequency 160 Hz, 6 kHz
Frequency range 40 Hz to 29 kHz (–16 dB)
54 Hz to 28 kHz (–10 dB)
Dimensions (WxHxD) 250 mm x 429.5 mm x 298.5 mm
Mass 6.1 k g
VK960 Surround speakers SB-PS960
Type 2 way, 3 speaker system (Bass refl ex)
Speaker unit(s) Impedance 3 Ω
1. Full range 8 cm Cone type
2. Full range 8 cm Cone type
3. Super tweeter Piezo type
Input power (IEC) 110 W (Max)
Output sound pressure 82 dB/W (1.0 m)
Cross over frequency 10 kHz
Frequency range 100 Hz to 24 kHz (–16 dB)
110 Hz to 22 kHz (–10 dB)
Dimensions (WxHxD) 140 mm x 331 mm x 146.5 mm
Mass 1.6 k g
VK960 Center speaker SB-PC960
Type 2 way, 3 speaker system (Bass refl ex)
Speaker unit(s) Impedance 3 Ω
1. Full range 8 cm Cone type
2. Full range 8 cm Cone type
3. Super tweeter Piezo type
Input power (IEC) 110 W (Max)
Output sound pressure 82 dB/W (1.0 m)
Cross over frequency 10 kHz
Frequency range 92 Hz to 27 kHz (–16 dB)
105 Hz to 25 kHz (–10 dB)
Dimensions (WxHxD) 330 mm x 104 mm x 94.5 mm
Mass 1.4 k g
VK860 Front speakers SB-PF860
Type 3 way, 3 speaker system (Bass refl ex)
Speaker unit(s) Impedance 3 Ω
1. Super woofer 20 cm Cone type
2. Woofer 12 cm Cone type
3. Tweeter 2.5 cm Titanium Dome type
Input power (IEC) 110 W (Max)
Output sound pressure 88 dB/W (1.0 m)
Cross over frequency 200 Hz, 6 kHz
Frequency range 40 Hz to 29 kHz (–16 dB)
54 Hz to 28 kHz (–10 dB)
Dimensions (WxHxD) 250 mm x 429.5 mm x 298.5 mm
Mass 6.1 k g
VK860 Surround speakers SB-PS860
Type 2 way, 3 speaker system (Bass refl ex)
Speaker unit(s) Impedance 3 Ω
1. Full range 8 cm Cone type
2. Full range 8 cm Cone type
3. Super tweeter Piezo type
Input power (IEC) 110 W (Max)
Output sound pressure 82 dB/W (1.0 m)
Cross over frequency 10 kHz
Frequency range 100 Hz to 24 kHz (–16 dB)
110 Hz to 22 kHz (–10 dB)
Dimensions (WxHxD) 140 mm x 331 mm x 146.5 mm
Mass 1.6 k g
VK860 Center speaker SB-PC860
Type 2 way, 3 speaker system (Bass refl ex)
Speaker unit(s) Impedance 3 Ω
1. Full range 8 cm Cone type
2. Full range 8 cm Cone type
3. Super tweeter Piezo type
Input power (IEC) 110 W (Max)
Output sound pressure 82 dB/W (1.0 m)
Cross over frequency 10 kHz
Frequency range 92 Hz to 27 kHz (–16 dB)
105 Hz to 25 kHz (–10 dB)
Dimensions (WxHxD) 330 mm x 104 mm x 94.5 mm
Mass 1.4 k g
VK960 Subwoofers SB-WVK960
VK860 Subwoofer SB-WVK860
Type 1 way, 2 speaker system (Bass refl ex)
Speaker unit(s) Impedance 3 Ω
1. Woofer 16 cm Aluminum Cone type
2. Woofer 16 cm Aluminum Cone type
Input power (IEC) 110 W (Max)
Output sound pressure 86 dB/W (1.0 m)
Frequency range 26 Hz to 310 Hz (–16 dB)
30 Hz to 250 Hz (–10 dB)
Dimensions (WxHxD) 200 mm x 429.5 mm x 359 mm
Mass 6.1 k g
VK760 Front speakers SB-PF760
Type 3 way, 3 speaker system (Bass refl ex)
Speaker unit(s) Impedance 3 Ω
1. Super tweeter Piezo type
2. Tweeter 6 cm Cone type
3. Woofer 16 cm Cone type
Input power (IEC) 110 W (Max)
Output sound pressure 82 dB/W (1.0 m)
Cross over frequency 4.16 kHz, 10 kHz
Frequency range 30 Hz to 28 kHz (–16 dB)
38 Hz to 21 kHz (–10 dB)
Dimensions (WxHxD) 220 mm x 330 mm x 182 mm
Mass 2.6 k g
VK760 Surround speakers SB-PS760
Type 1 way, 1 speaker system (Bass refl ex)
Speaker unit(s) Impedance 3 Ω
1. Full range 6.5 cm Cone type
Input power (IEC) 110 W (Max)
Output sound pressure 80 dB/W (1.0 m)
Frequency range 95 Hz to 25 kHz (–16 dB)
110 Hz to 22 kHz (–10 dB)
Dimensions (WxHxD) 270 mm x 92 mm x 95.4 mm
Mass 0.9 k g
