Unpacking the 904 Total Body Treadmill
All Precor products are thoroughly tested and inspected before shipment.
Precor ships the 904 treadmill in seven pieces:
• Deck or treadmill’s base assembly
• Handrails (right and left)
• Front lift bar
• T-knob assembly
• Literature kit (not shown) and Hardware kit (contents shown in Diagram 2)
Diagram 1 shows the treadmill’s parts after opening the carton. Callouts point
to the different parts of the treadmill that are discussed in the assembly
instructions. Unpack the treadmill close to the location where you plan to use it.
Note: Save the triangular, cardboard end block for use in the assembly.
Right handrail mount
Diagram 1
Unassembled 904 treadmill.
Handrail (right)
Front lift bar
Running belt
Micro-adjustment cable
Flywheel
Side rail
Handrail (left)
Cardboard end block
T-knob assembly
