SAFETY GUIDELINES - DEFINITIONS
It is important for you to read and understand this manual. The information it contains
relates to protecting YOUR SAFETY and PREVENTING PROBLEMS. The symbols
below are used to help you recognize this information.
Indicates an imminently hazardous situation which, if not avoided, will
result in death or serious injury.
Indicates a potentially hazardous situation which, if not avoided, could
result in death or serious injury.
Indicates a potentially hazardous situation which, if not avoided, may
result in minor or moderate injury.
Used without the safety alert symbol indicates a potentially hazardous
situation which, if not avoided, may result in property damage.
:
:
:
:
FUNCTIONAL DESCRIPTION
Figure A
1. On/Off slider switch
2. Spindle lock button
3. Depth guide
4. Depth guide adjustment screws
5. Depth guide removal screw
6. Collet
7. Collet nut
8. Battery (not included)
9. Battery Release Button (on battery)
3
1
2
4
5
A
8
9
6
7
LI-ION Battery Packs and Chargers
Battery: LI-ION 18V
Charger: LI-ION
PC18BL
PC18BLX
PC18BLEX
PCLMVC
PCXMVC
Description Cat. #
NI-CD Battery Packs and Chargers
This product can accept any of the batteries and chargers listed in the chart below.
Battery: NI-CD 18V
Charger: NI-CD PC18B
PCMVC
PCXMVC
Description Cat. #
