Page 84: Amibios setup - hardware monitor setup

CHAPTER 3
AMI
®
BIOS USERS GUIDE
3-23
Hardware Monitor Setup
The Hardware Monitor Setup is used to set the CPU speed and
monitor the current CPU Temperature, CPU Fan speed, Chassis Fan Speed,
Power fan speed, Vcore, etc. This is only available if there is Hardware
Monitor onboard.
1. Press
screen.
2. Use
3. After you have finished with the Hardware Monitor Setup, press
-==System Hardware Monitor==-
Chassis Intrusion
:Disabled
CPU Temperature
:40
O
C/104
O
F
System Temperature
:32
O
C/89
O
F
CPU Fan Speed
:0 RPM
System Fan Speed
:0 RPM
Power Fan Speed
:4354 RPM
CPU VID
:1.75V
Vcore
:1.648 V
1.8V
:1.824 V
Vio
:3.312 V
+ 5.0V
:5.223 V
+ 12.0V
:11.376 V
- 12.0V
:-11.497 V
- 5.0V
:-4.926 V
Battery
:3.136 V
+5V SB
:5.090 V
ESC:Quit
↑↓ ←→
↑↓ ←→
↑↓ ←→
↑↓ ←→
↑↓ ←→
:Select Item
F1 :Help
PU/PD/+/- : Modify
F5 :Old Values (Shift)F2: Color
F6 :Load BIOS Defaults
F7 :Load Setup Defaults
AMIBIOS SETUP - HARDWARE MONITOR SETUP
(C) 1999 American Megatrends, Inc. All Rights Reserved
