20
1
Be
fo
re
Us
ing Yo
ur Ca
m
e
ra
Viewfinder Indications
1 Autofocus frame (p.39)
2 Spot metering frame (p.130)
3 Flash status (p.49)
Appears when flash is available and blinks when flash is recommended but
not set.
4 Manual white balance (p.113)
Appears when manual white balance is in use and blinks while adjusting.
5 Continuous mode (p.122)
Appears when focus mode is set to k (Continuous mode).
6 Picture mode icon (p.47)
Icon for Picture mode in use appears.
.
Night Scene Portrait, \ Moving Object, q Macro, s Landscape,
= Portrait, U Normal
7 Focus indicator (p.44)
Appears when image is focused. When blinking indicates an out of focus
subject.
8 Shutter speed (p.134)
Shutter speed when capturing or adjusting (underlined when shutter speed
can be adjusted with e-dial).
9 Aperture (p.136)
Aperture when capturing or adjusting (underlined when aperture can be
adjusted with e-dial).
1
3 4 5
12 13 14
6
7 8 9 10 11
2
1
