8

LX0801PTI/ LX1201PTI/ LX1501PTI - IP-65 Touch Monitors User’s Guide (020-0512-01A)

Features

Brightness control

allows you to easily adjust the display to match the

ambient light, from full sunlight to night.

The monitor’s

TFT display is optically bonded to the Touchscreen to

increase contrast ratio. Increased contrast ratio makes it easier to
read information displayed on the monitor.

The monitor’s

autosync function eliminates the need for adjusting the

monitor for the best image - the monitor automatically makes any needed
adjustments whenever it is powered up or the display mode is changed.

The monitor supports

standard VGA signal input:

LX0801PTI is 800 x 600 SVGA (native) and 640 x 480.

LX1201PTI and LX1501PTI are 1024 x 768 (native), 800 x 600 and

640 x 480.

The monitor’s IP-65

enclosure protects from splashed water and dust. It

is designed to withstand shock and vibration for greater endurance and
reliability.

There are several mounting point features incorporated in the design of

the enclosure to enable installation fl exibility.

Note: The LX0801PTI/LX1201PTI/LX1501PTI monitors do not have OSD controls
available from the front buttons. All OSD commands can be controlled via USB
cable from the host CPU (see Addendum A).
