background image

LX0801PTI/ LX1201PTI/ LX1501PTI - IP-65 Touch Monitors User’s Guide (020-0512-01A)

21

Specifi cations

Parameter

LX1501PTI - 15"

Display Type

Full Color TFT AMLCD

Display Viewing Area

304 (w) x 228 (h) mm

Diagonal Viewing Area

15" (381 mm)

Display Color

262 K (6 bit/color); 16.7 m (8 bit)

Resolution

1024 (H) x 768 (V) pixels XGA

Contrast Ratio

650:1 (typical)

Response Time

25 ms (on/off )

Luminance

1200 Nits (typical)

Horizontal Viewing Angle (CR>5)

80° (right), 80° (left)

Vertical Viewing Angle (CR>5)

80° (down), 70° (up)

Video Input

VGA

Backlight

6 CCFLs

Backlight Adjustment

0-100% dimmable

Backlight Inverter

Pizeoelectric, dims to off

Power Consumption

<45 Watts (total), 4.2W standby typical with USB
connected; 3.6W standby typical without USB.

Touch screen

Infrared, 4096 points of resolution

Touch screen Interface

USB

Cover Glass

AG etched, direct bonded

Operating Survival Temp Range

-40° C to + 70° C

Operating Temperature

-20° C to + 70° C

Storage Temperature

-20° C to + 80° C

Shock

30 Gs, Half Sine Wave, 11 ms

Vibration, Endurance

10-500 Hz, 2 Gs rms, 1hr/axis

Vibration, Operating

10-500 Hz, 2 Gs rms, 1hr/axis

Humidity

90% RH @ 40° C, Non-condensing

Emission

EN 55022, EN6100-3-2, -3

Immunity

IEC 6100-4-2, -3, -4, -5, -6, -8, -11: 1995

Reverse Polarity Protection

Protected

Regulatory and Safety

FCC Class B, CE, UL/CUL, TUV

Enclosure Including Front Bezel

IP-65 (Waterproof )

Input/Outputs

Power On/Off Button
Dimming/Auto Sync rocker switch
Watertight USB “B” Type
Watertight VGA 15-Pin
Watertight Power Connector (LTW p/n LTWCD-07BFFA-
LL7001 is fi eld installable mating connector)
