LX0801PTI/ LX1201PTI/ LX1501PTI - IP-65 Touch Monitors User’s Guide (020-0512-01A)

23

Parameter

LX0801PTI - 8.4"

Display Type

Full Color TFT AMLCD

Display Viewing Area

170 (w) x 127 (h) mm

Diagonal Viewing Area

8.4" (213 mm)

Display Color

262 K (6 bit/color); 16.7 m (8 bit)

Resolution

1024 (H) x 768 (V) pixels XGA

Contrast Ratio

650:1 (typical)

Response Time

-

Luminance

700 Nits (typical)

Horizontal Viewing Angle (CR>5)

80° (right), 80° (left)

Vertical Viewing Angle (CR>5)

60° (down), 80° (up)

Video Input

VGA

Backlight

2 CCFLs

Backlight Adjustment

0-100% dimmable

Backlight Inverter

Pizeoelectric, dims to off

Power Consumption

<15 Watts (total), 4.2W standby typical with USB con-
nected; 3.6W standby typical without USB.

Touch screen

Infrared, 4096 points of resolution

Touch screen Interface

USB

Cover Glass

AG etched, direct bonded

Operating Survival Temp Range

-40° C to + 70° C

Operating Temperature

-20° C to + 60° C (-4° to 140° F)

Storage Temperature

-20° C to + 85° C (-4° to 185° F)

Shock

18 Gs, SAE J1455

Vibration, Endurance

100-1100 Hz, 4 Gs rms, 1hr/axis

Vibration, Operating

5-150 Hz, 4 Gs rms, 1hr/axis

Humidity

95% RH, Non-condensing

Emission

-

Immunity

-

Reverse Polarity Protection

Protected

Regulatory and Safety

FCC Class A, CE, UL/CUL, TUV

Enclosure Including Front Bezel

IP-65 (Waterproof )

Input/Outputs

Power On/Off Button
Dimming/Auto Sync rocker switch
Watertight USB “B” Type
Watertight VGA 15-Pin
Watertight Power Connector (LTW p/n LTWCD-07BFFA-
LL7001 is fi eld installable mating connector)
