Packard Bell EasyNote MX Disassembly Manual
4
Battery
Perform the following steps to remove the battery:
1. Make sure the power is off.
2. Turn the notebook upside down.
Note: Use an anti-static mat or something soft like a piece of cloth underneath the notebook to prevent damage
to the exterior of the notebook.
3. Push the 2 locks in the direction of the arrows to the release the battery compartment cover and
remove the cover.
4. Take the battery out of the compartment.
Fig. 1 Removing battery.
Hard Disk Drive
To remove the HDD, first remove the battery (see Battery ) and then perform the following steps:
1. Remove the 2 screws on the hard disk drive cover and remove the cover (see Fig. 1 ).
2. Pull the plastic tab on the hard disk drive towards you as shown in Fig. 2 to disconnect the drive.
Fig. 2 Removing hard disk drive.
3. Take the drive out of its compartment.
