26
The “GPI CONTROL” item is used to set enable/disenable of all GPI functions, and assigns functions to each of the
GPI terminal pins (J page 30).
The underlined values are factory preset setting values.
Note:
Please be aware that the following can not be performed.
• “SD ASPECT” operation when input signal is HD or PC
• “SCAN” operation when the input signal is PC
• “GAMMA SELECT” operation when the input signal is PC
• “RGB SYNC” operation when anything other than “RGB-VIDEO” is selected in “YP
B
P
R
/RGB” in the “INPUT
SELECT” menu
• “MONO” operation when input signal is PC
GPI
Sub menu Settings Explanation
GPI CONTROL GPI functions enable/disenable settings
GPI1–GPI8
B
P
R
/RGB>
PST>
Used to set the GPI control terminal pin assign.
You can set the same items for each terminal
(refer to page 30 for details).
Main Menu
(continued)
