Connections and Setup
16
For fax advantage assistance, call 1-800-435-7329.
Case 1: Receives faxes and phone calls (on
answering machine) on single line (one phone
number)
Your situation
You wish to use the fax machine and your
answering machine in the same room.
Telephone wiring image in
house or office
Connections
Fax
machine
Answering
machine
Answering machine
(Not included)
Telephone
line cord
To a single
telephone line
jack (RJ11C)
To a power
outlet
(120 V, 60 Hz)
Power cord
Remove the stopper.
