Control reference guide
Remote control
1 Turn this unit on or off
2 Select the audio source
3 Basic playback control buttons
4 Enter setup menu
5 Enter the iPod/iPhone menu /
Change displayed information
6 Open/close the sliding door
7 Adjust the volume
8 Mute the sound
Mutes the sound. Press again to
cancel. “MUTE” is also canceled
when the volume is adjusted or the
unit is turned off.
9 Enter playback menu
10 Enter sound menu
11 Selection/OK
∫ Preparation
Remove the insulation sheet A before using.
∫ To replace a button-type battery
1 While pressing the stopper B,
pull out the battery holder. 2 Set the button-type battery
with its (i) mark facing
upward and then put the
battery holder back in place.
Keep the button-type battery out
of reach of children to prevent
swallowing.
Battery type: CR2025 (Lithium battery)
≥ The battery should normally last about 1 year, however this depends on how
frequently the unit is used.
Main unit
1 Standby/on switch [Í/I]
Press to switch the unit from on to standby mode or
vice versa.
In standby mode, the unit is still consuming a small
amount of power.
2 Open/close the sliding door (for iPod/iPhone)
3 Select the audio source
4 Basic playback control buttons
5 Adjust the volume (0(min) to 50(max))
6 Open/close the sliding door (for discs)
7 Dynamic Bass sound effect selector
8 Headphone jack
Plug type: ‰3.5 mm ( 1 /
8
q) stereo
Recommended plug type: Straight Plug
≥ To prevent hearing damage, avoid listening for
prolonged periods of time.
Excessive sound pressure from earphones and
headphones can cause hearing loss.
9 Standby indicator
10 Display
11 Sliding door
12 Remote control signal sensor
Distance:
Within approx. 7 m (23 ft) directly in front.
≥ To avoid interference, please do not put any objects
in front of signal sensor.

8
10 11
12
Top view
