Either 10 Points or the Maximum of 128 Points
You save this much space!
3
The expansion unit can be attached easily
without any cables.
The expansion unit can easily be attached directly to the
control unit. Special expansion cables, backplanes, and
so forth, are unnecessary as the expansion unit employs
a stacking system that uses expansion connectors and
locking levers on the surface of the unit itself.
Because of its super compact size and high capabilities,
the units are useful in a wide variety of applications.
Relay sequence
replacement In-house detectors Conveyer control
Parts feeders Food processing and
packaging machines Parking meters
Auto-stockers Driving range
Easy Expansion
…up to 128 I/Os
Control
unit
Expansion
unit
Expansion
unit
Expansion
unit
(Maximum possible expansion is three units)
Control unit Expansion unit Expansion unit Expansion unit
105mm
The photo illustrates adding
three I/O 32-point expansion
units to an I/O 32-point control
unit, yielding 128 points.
Supply voltage 24VDC.
■ Networking:
- ETHERNET
- PROFIBUS
- S-LINK
- MEWNET-F
■ Analogue modules featuring
different numbers of input and
output channels
■ Programming software:
- Control FPWIN Pro according
to IEC 61131-3
- Control FPWIN GR easy,
conventional programming
