FP0 Series
Specification tables
Item Description
Programming TOOL-Port
Communication COM-Port
RS232, mini DIN socket (5 pin), 9600 or 19200 BAUD, (8 data bits, odd parity, 1 stop bit), Computer link for
programming and communication with MEWTOCOL.COM, user configurable modem connection
RS232 (SD, RD, GND) 3 way screw terminal, 300 to 19200 BAUD, (7 or 8 data bits, none/even/odd parity,
1 or 2 stop bits, start code: none/STX, end code: CR/CR+LF/ETX/none, CCU mode for programming and
communication with MEWTOCOL.COM, user configurable modem connection, GENERAL PURPOSE MODE
controlled by program for general purpose RS232 communication.
Note: (*): Since the response time of X0 to X5 is very fast (for high-speed counter input), the FP0 happens to catch chattering noise as an input signal.
To prevent this, it is recommended that timer instruction should be included in the program.
Notes:
(*1): 8points/common(C16T/C16P,E16T/E16P), 16points/common(C32T/C32P,
T32CP, E32T/E32P)
(*2): 50µs or less at Y0, Y1 only
The FP0 series conforms to the following standards under the EMC Directive
and the Low Voltage Directive.
EMC Directive (89/336/EEC) Low Voltage Directive (73/23/EEC)
EN 50081-2: 1993 VDE 0160: 1988 (EN 50178: 1995)
EN 50082-2: 1995 (Overvoltage Category II,
non-mains-circuit, pollution degree 2)
EN 61131-2: 1995
Interfaces
Item
Insulation method Optical coupler
Rated input voltage 24VDC
Operating voltage range 21.6 to 26.4VDC
Rated input current 4.3mA or less (at 24VDC)
Input points per common 6 points/common (C10RS) 8 points/common (C14RS,C16T/C16P,E16T/E16P) 16 points/common (C32T/C32P,E32T/E32P)
ON voltage/ON current 19.2V or less/ 3mA or less
OFF voltage/OFF current 2.4V or more/ 1mA or more
Input impedance Approx. 5.6k Ω
Response time
OFF➔ ON
50µs or less (at X0,X1)(*)
100µs or less (at X2 to X5)
2ms or less (at X6 to XF)
ON➔ OFF same as above
Operating indicator LED display
Description
Input specifications
Item
1) Relay output type
Output type Normally open(1 Form A)
Rated control capacity
OFF➔ ON
ON➔ OFF
Mechanical
Electrical
2A 250VAC, 2A 30VDC(4.5A/common)
Response time
10ms or less
8ms or less
Life
20million operations or more
100k operations or more
Surge absorber None
Operation indicator LED display
Description
Output specifications
Item
2) Transistor output type
Insulation method Optical coupler
Output type Open collector
Rated load voltage 24VDC 5 to 24VDC
Load voltage allowable range 4.75 to 26.4VDC
Max. load current 0.1A/points(at DC26.4V) (1A/common)(*1)
Max. inrush current 0.3A
Leakage current at OFF time 100µA or less
Max. voltage down at ON time
Response time
1.5V or less
OFF➔ ON 1ms or less
ON➔ OFF 1ms or less(*2)
Surge absorber Zener diode
Operating indicator LED display
Description
External power
supply
(For internal circuit) Voltage 21.6 to 26.4VDC
Current 240mA or less
