116
SPECIFICATIONS
Sportsman 500 EFI Tractor
Maximum Weight Capacity 420 lbs. (191 kg) (includes operator, cargo, acces-
sories, tongue weight)
Dry Weight 775 lbs. (352 kg)
Front Rack/Storage Box Capacity 90 lbs. (41 kg)
Rear Rack Capacity
180 lbs. (82 kg)
Rear Hitch Tongue Capacity 120 lbs. (54.4 kg) (Rear rack capacity and tongue
weight not to exceed 180 lbs./82 kg)
Rear Hitch Towing Capacity 1225 lbs. (555 kg) on level ground
Front Hitch Tongue Capacity 85 lbs. (39 kg) (Front rack capacity and tongue
weight not to exceed 90 lbs./41 kg)
Front Hitch Towing Capacity 850 lbs. (386 kg)
Overall Length 83 in. (211 cm)
Overall Width 48 in. (122 cm)
Overall Height 48 in. (122 cm)
Wheelbase 50.5 in. (128 cm)
Ground Clearance 11 in. (28 cm)
Minimum Turning Radius 65 in. (165 cm) unloaded
Fuel Capacity 4.12 gal. (15.6 l)
Engine Oil Capacity 2 qts. (1.9 l)
Coolant Capacity 2.7 qts. (2.5 l)
Demand Drive Fluid Capacity 9.3 oz. (275 ml)
Transmission Oil Capacity 32 oz. (948 ml)
Engine EH50PLE
Displacement 498 cc
Bore x Stroke 92mm x 75mm
Alternator Output 350 w
Compression Ratio 10.2:1
Fuel System Electronic Fuel Injection
Ignition System Electronic Ignition
Ignition Timing 10 +/- 1 BTDC @ idle
Spark Plug NGK BKR6E
Spark Plug Gap .035+0.0/-0.004 in. (0.9+0.0/-0.1 mm)
Lubrication System Dry Sump
Driving System Type Automatic PVT (Polaris Variable Transmission)
Front Suspension MacPherson strut with 8.2" (21 cm) travel
Rear Suspension Progressive rate with 9.5" (24 cm) travel
