117
SPECIFICATIONS
Clutching (EBS Models)
*EBS models require no helix/spring adjustment
Sportsman 500 EFI Tractor
Transmission Automatic EBS (Engine Braking System)
w/E-Z Shift H/L/N/R/P
Gear Reduction, Low 23.91:1
Gear Reduction, Reverse 21.74:1
Gear Reduction, High 10.57:1
Drive Ratio, Front 3.82:1
Tires/Pressure, Front 25x8-12 / 5 psi (34.5 kPa)
Tires/Pressure, Rear 25x12.5-12 / 5 psi (34.5 kPa)
Brake, Hand All-wheel hydraulic disc
Brake, Foot All-wheel hydraulic disc
Brake, Parking Transmission park lock and hydraulic lock, all
wheel
Headlight 2 Hi/Lo beam on bumper (37.5 watt)
Parking Lights 5 watts
Taillights 8.26 watts
Brake Light 26.9 watts
Instrument Cluster LCD
Altitude Shift
Weight
Drive Clutch
Spring
Driven
Clutch
Spring
Helix*
Meters
(Feet)
0-1800
(0-6000)
10 WH
PN 5630710
Blue/Green
PN 7041157
White/Yellow
PN 7041635
EBS
PN 5131674
1800-3700
(6000-12000)
10 RH
PN 5630709
Blue/Green
PN 7041157
White/Yellow
PN 7041635
EBS
PN 5131674
