V/H
SYNC+Blank
This selection will cause the system to turn off the vertical and
horizontal synchronization ports and write blanks to the video buffer.
Blank Screen This option only writes blanks to the video buffer.
DPMS Initial display power management signaling.
Suspend Type
Select the Suspend Type.Configuration options: PWRON Suspend / Stop Grant
Suspend Mode
When enabled and after the set time of system inactivity, all devices except the CPU
will be shut off. Configuration options: Disabled / 1 Min / 2 Min / 4 Min / 8 Min / 12
Min / 20 Min / 30 Min / 40 Min / 1 Hour .
HDD Power Down
When enabled and after the set time of system inactivity, the hard disk drive will be
powered down while all other devices remain active.
Configuration options: Disabled / 1 Min / 2 Min / 3 Min / 4 Min / 5 Min / 6 Min / 7 Min
/ 8 Min / 9 Min / 10 Min / 11 Min / 12 Min / 13 Min / 14 Min / 15 Min
Soft-Off by PWR-BTTN : When set to delay 4 sec, the function allows the power button to
put the system in Suspend, a power saving mode. When set to Instant-off the Soft-Off
by PWR-BTTN function is disable and the computer turns completelyoff when the
power button is pressed.
Wake-Up by PCI card: Enable this selection to use the Wake up by PCI card.
Resume by Alarm
You can set "Resume by Alarm" item to enabled and key in Data/ time to power on
system.
Disabled Disable this function.
Enabled
Enable alarm function to POWER ON system.
If RTC Alarm Lead To Power On is Enabled.
Date (of Month ) Alarm : Every day , 1~31
Time (hh: mm: ss) Alarm : (0~23) : (0~59) : (0~59)
FDD,COM,LPT Port
Configuration options: Enabled / Disabled
PWRON After PWR-Fail : Select Enabled, this setting will let the power switch always
under on-line status after commercial power back to normal.
