14
30 AD 19 Ground
31 +3.3V AD 18
32 AD 17 AD 16
33 C/BE 2 # +3.3V
34 Ground FRAME#
35 IRDY# Ground
36 +3.3V TRDY#
37 DEVSEL# Ground
38 Ground STOP#
39 LOCK# +3.3V
40 PERR# Reserved*
41 +3.3V Reserved*
42 SERR# Ground
43 +3.3V PAR
44 C/BE 1 # AD 15
45 AD 14 +3.3V
46 Ground AD 13
47 AD 12 AD 11
48 AD 10 Ground
49 M66EN AD 09 66MHZ/gnd
50 Ground Ground 5 volt key
51 Ground Ground 5 volt key
52 AD 08 C/BE 0 #
53 AD 07 +3.3V
54 +3.3V AD 06
55 AD 05 AD 04
56 AD 03 Ground
57 Ground AD 02
58 AD 01 AD 00
59 +3.3V I/O +3.3V I/O
60 ACK64# REQ64#
61 +5V +5V
62 +5V +5V 32-bit connector end
