On-Chip (Primary/Secondary) PCI IDE : The Intel 82C440BX chipset
contains a PCI IDE interface with support for two IDE channels. Select Enabled to
activate the primary and/or secondary IDE interface. Select Disabled to deactivate
this interface, if you install a primary and/or secondary add-in IDE interface.
On-Chip Serial ATA
This item allows you to configure your serial ATA devices if present.
Disabled
Disable SATA controller.
Auto Auto arrange by BIOS.
Combined
Mode
PATA and SATA are combined. Max.of 2 IDE drives in each
channel.
Enhanced
Mode
Enabled both SATA and PATA. Max.of 6 IDE drives are
supported.
SATA First
SATA is operating in legacy mode.
Note. The items SATA mode, Serial ATA Port0 Mode, and Serial ATA Port1
Mode are configurable only when the ON-Chip Serial ATA item is not set to
[Disabled].
Serial ATA Port0 Mode
Primary Master
Remap SATA Port 0 to IDE Pri. Master.
Primary Slave Remap SATA Port 0 to IDE Pri. Slave.
Secondary Master
Remap SATA Port 0 to IDE Sec. Master.
Secondary Slave
Remap SATA Port 0 to IDE Sec. Slave.
P-SATA master Remap SATA port 0 to P-SATA Master.
S-SATA master
Remap SATA port 0 to S-SATA Master.
Onboard Device : Scroll to this item and press to view the following screen:
USB Controller: Select Enabled if your system contains a Universal Serial Bus
(USB) controller and you have USB peripherals
USB 2.0 Controller
Disable this function if you are not using onboard USB 2.0 feature.
Enabled
Enable USB 2.0 Controller.
Disabled
Disable USB 2.0 Controller.
USB Keyboard Support : Select Enabled if your system contains a Universal
Serial Bus (USB) controller and you have a USB keyboard.
