USB Mouse Support: Select Enabled if you need to use a USB inferfaced Mouse
in the operating system
SuperIO Device : Scroll to this item and press
Watch Dog : Enable / Disable the Watch dog function.
By Pass Function : Enable / Disable the LAN By Pass Function
LPT/LCM CONTROL :Use this option to enable and configure or disable the
LPT/LCM port present on the evaluation board.
Configuration options: LPT / LCM
SIGNAL DUAL STATUS LED
This setting is to set the status when the system is powered on.
Configuration options: Green / RED
STATUS LED
This setting is to set the status when the system is powered.
Configuration options: Always Blight / DARK / 0.1 sec BLINK / 0.5 sec BLINK
Onboard Serial Port 1 / Port 2 : : Select an address and corresponding interrupt
for the first and second serial ports. The settings are “3F8/IRQ4”, “2E8/IRQ3”,
“3E8/IRQ4”, “2F8/IRQ3”, “Disabled”, “Auto”.
Onboard Parallel Port : This item allows you to determine onboard parallel port
controller I/O address setting. The settings are “378H/IRQ7”, “278H/IRQ5”,
“3BC/IRQ7”, “Disabled”.
Parallel Port Mode : Select an operating mode for the onboard parallel (printer)
port. Select “Normal”, “Compatible”, or “SPP” unless you are certain your
hardware and software both support one of the other available modes.
EPP Mode Select : Select EPP port type 1.7 or 1.9.
ECP Mode Use DMA : Select a DMA channel for the parallel port for use during
ECP mode. The settings are “3” and “1”.
