Lanner electronic FW-7890 User Manual
Page 14
7
5
Data 6
6
Data 9
7
Data 5
8
Data 10
9
Data 4
10
Data 11
11
Data 3
12
Data 12
13
Data 2
14
Data 13
15
Data 1
16
Data 14
17
Data 0
18
Data 15
19 Ground 20
KEY
21
DMA REQ# 22
Ground
23 IOW
# 24
Ground
25 IOR
# 26
Ground
27 IOCHRDY 28
Ground
29
DMA ACK #
30
Ground
31 Interrupt 32
NC
33
SA1
34
PD80P / SD80P
35
SA0 36
SA2
37
HDC CS0 #
38
HDC CS1 #
39
HDD Active LED #
40
Ground
FAN1~3 : 3 Pin FAN Connector
Pin No.
Description
1 Ground
2 +12V
3 NC
IDEB1
2
1
39
40
F
AN1
1
2
3
