Little Wonder 2300 User Manual
Page 20
20.
Key
No.
Part No.
Description
Qty.
1 5580-12110
CYLINDER
1
2 5500-12213 GASKET,
base
1
3 1850-12130
BOLT
2
4
5602-73110
PLUG RCJ-6Y
1
5 5500-21100 CRANKCASE-C
1
6
2629-21130 •
PIN
3
7 5500-21141
GASKET
1
8 06030-06001
BEARING
2
9 2169-21210 SEAL
1
10 1850-21220 SEAL
1
11 04065-02812 SNAP
RING
1
12 01252-30530 BOLT
3
13 5500-22110 GUARD
1
14 0263-90514 SCREW
1
15 5500-42001 CRANKSHAFT-C
1
16 5600-41111 PISTON
1
17 1100-41210 RING
2
18 1101-41310 PIN
1
19 1260-41320 RING
2
20 5500-41410 BEARING
1
21 1101-41340 WASHER
2
22 T1702-15100
MUFFLER
ASSY
1
23 1601-15120 ARRESTER
1
24 01252-30550 BOLT
2
25 T1600-15210 GASKET
1
26 5500-15221 PLATE
1
27 0263-90416 SCREW
1
28 T1700-13160 INSULATOR
1
29 5500-13121 GASKET,
insulator
1
30 5500-13131 GASKET,
carburetor
1
31 0263-90520 SCREW
2
32 5501-81000 CARBURETOR
ASS'Y
1
33
1850-81450
• BODY ASS'Y
1
34
3306-81380
• • SCREEN
1
35
3356-81310
• • VALVE
1
36
1850-81270
• • SPRING
1
37
1850-81220
• • SCREW
1
38
3310-81250
• • PIN
1
39
3310-81230
• • LEVER
1
40
1850-81490
• BODY, purge
1
41
1850-81520
• COVER, pump
1
42
1751-81510
• PUMP, priming
1
43 3310-81260 •
DIAPHRAGM
1
44
1850-81470
• GASKET, diaphragm
1
45
1065-81420
• DIAPHRAGM, pump
1
46
1065-81410
• GASKET, pump
1
47 5500-81251 •
JET
1
48 1751-81240 •
RING
1
49 1751-81130 •
RING
1
50 1881-81140 •
SWIVEL
1
51 1752-81110 •
SCREW
2
52 5500-81120 •
BRACKET
1
53
1751-81180
• NUT, adjuster
1
54
1918-81170
• SCREW, adjuster
1
55 1881-81130 •
RING
1
56 1850-81530 •
SCREW
4
57 5500-81160 •
WASHER
1
58 T1700-82100 BODY-ASSY
1
59 5500-82111 •
BODY
1
60 1970-82190 •
SLEEVE
2
61
T1700-82130
• PLATE, choke
1
62
T1700-82140
• LEVER, choke
1
Key
No.
Part No.
Description
Qty.
63 2630-33610 •
SCREW
1
64 5500-82171 ELEMENT
1
65 T1701-82200 COVER
ASS'Y
1
66 5500-82221 •
KNOB
1
67 0263-90560 SCREW
2
68 T1702-31100 HOUSING-ASS`Y
1
69 T1701-31110 •
HOUSING
1
70 06002-06001 •
BEARING
1
71 4810-31120 •
DRUM
1
72 04064-01210 •
RING
1
73 04065-02812 •
RING
1
74 T1700-31211 BRACKET
(A)
1
75 T1700-31221
BRACKET
(B)
1
76 T1700-31231 CUSHION
1
77 01252-30522 BOLT
2
78 01252-30510 BOLT
1
79 0263-90520 SCREW
4
80 T1700-32110 COVER,
engine
1
81 T1700-32160 SCREW
1
82 0263-90514 SCREW
1
83
1140-51111
SHOE
2
84 T1700-51220 SPRING
1
85 1140-51250 SCREW
2
86 1140-51230 WASHER
2
87 1970-51241 WASHER
2
88 T1700-71110 ROTOR
1
89 T1700-71200 COIL-A
1
90 5500-72110 •
CAP
1
91 T1700-71220 •
CORD
1
92 2616-71320 •
CAP
1
93 5500-72130 •
GROMMET
1
94 5500-72120 •
SPRING
1
95 3310-72150 BOLT
2
96 T1700-71260 SPACER
2
97 T1700-73200 CORD-C
1
98 1650-43230 NUT
1
99 1000-43240 KEY
1
100 T1700-75100 RECOIL
ASS'Y
1
101 5500-75110
•
CASE-C
1
102 1850-75120
•
REEL
1
103 1850-75130
•
SPRING
1
104 1850-75151
•
SCREW
1
105 T1600-75160 •
ROPE
1
106 T1600-75310 •
KNOB
1
107 T1600-75320 •
COLLAR
1
108 T1600-75330 •
SPRING
1
109 T1600-75210 •
WASHER
1
110 1850-75201
PULLEY
ASS'Y
1
111 1850-75221
•
RATCHET
1
112 1850-75230
•
SPRING
1
113 T1700-32160 SCREW
4
114 T1700-85000 TANK
ASS'Y
1
115
5607-85201
• CAP ASS'Y
1
116
5601-85300
• • HOLDER ASS'Y
1
117
5500-85220
• • PACKING
1
118
5601-85260
• • FILTER
1
119 4810-85300
•
PIPE-C
1
120
5500-85400
• FILTER ASS'Y
1
121 1260-85460
•
CLIP
1
122 5910-85510
SCREW
3
123 1950-86120
CLIP
1
124 T1702-75410 LABEL,
recoil
1
