Read This First
Printer Rear
This is a rear view of the printer.
1. Duplex unit cover button
Press to open the duplex unit cover.
2. Vent
Air is vented here to prevent the inside of the printer from getting too warm. Do not lean anything against the vent or
block it in any way. If the inside of the printer gets too warm, a breakdown could occur.
3. Paper feed wheel
Use to wind out paper jammed around the guide board.
4. Power cord
Plug the power cord into a wall outlet.
Connect the grounding wire attached to the power plug directly to a grounding terminal.
5. Duplex unit
Turns the paper over when performing duplex printing.
6. Guide board
Open to remove paper jammed inside the printer.
7. Duplex unit cover
Open to remove paper jammed inside the duplex unit.
8. Duplex unit locks
Use to lock or unlock the duplex unit when attaching or detaching it.
9. Ethernet Port
Use a network interface cable to connect the printer to a network.
