Lexmark 258x - Manual (Page 30)

Print Position
2-10
Draft document
USAGE NOTES
•
The default is 1/216 inch. The supported alternative is 1/180 inch and 1/360
inch.
•
n1 and n2 specify the number of mode bytes contained in this escape
sequence. Normally, n1 is 4, and n2 is 0.
•
m1 and m2 are ignored.
•
m3 and m4 set the base units as follows:
Select 1/8" Line Spacing
This command (ESC zero) sets the line spacing at 1/8 inch between each line, which
is 8 lines per inch (lpi).
Select 7/72" Line Spacing
This command sets the line spacing at 7/72 inch between each line, which is 10.3 lpi.
Table 2-3: Set Vertical Unit - m3 and m4 values
m3 m4
Unit Decimal Hexadecimal Decimal Hexadecimal
216 D8 00 00 1/216
180 B4 00 00 1/180
104 68 01 01 1/360
Format ESC 0
Decimal 27 48
Hexadecimal 1B 30
Format ESC 1
Decimal 27 49
Hexadecimal 1B 31
