Life Fitness GS2 User Manual
Page 17
S
TEP
15:
• Slip ring of WEIGHT SELECTOR PIN (51) down WEIGHT STACK SHAFT and insert pin into one
of the weights
• Screw end of LAT CABLE (20) into top of PLATE SHAFT (18) and securely tighten JAM NUT as
shown in FIGURE 15
• Securely tighten 1/2” LOCK NUT (35) on PRIMARY PIVOT of PRESS ARM (9).
17
20
51
35
F
IGURE
15
0
1
2
3
4
5
6
1/2
1/2
1/2
1/2
1/2
1/2
SECURELY
TIGHTEN
JAM NUT
WEIGHT
STACK
SHAFT
