11 s – Life Fitness GS2 User Manual
Page 13
20
21
32
55
1
11
56
35
1/2 X 104mm
13
S
TEP
11:
• Assemble the LEG PEDESTAL (11) to the FRAME (1) using one 1/2 X 104mm BOLT (32), two
RH WASHERS (56) and one 1/2” LOW HT LOCK NUT (35)
• Assemble two RH CAPS (55) to the 1/2” RH WASHERS (56) as shown in FIGURE 11
F
IGURE
11
S
TEP
12:
• Route LAT CABLE (20) and LOW CABLE (21) as shown in FIGURE 12
0
1
2
3
4
5
6
1/2
1/2
1/2
1/2
1/2
1/2
F
IGURE
12
