56 Ceiling Cassette Air Conditioner
Exploded View and Replacement Parts List
Parts List
137213-1 PANEL ASSEMBLY,SIDE 1A00202F R
137213-2 PANEL ASSEMBLY,SIDE 3A02284N R
567480 -1 THERMISTOR,NTC 6323A20028B R
567480 -2 THERMISTOR,NTC 6323A20023E R
349480 ORIFICE 4948AP2527A R
349600 BRACKET,MOTOR 1A00206B R
430410 BASE ASSEMBLY,OUTDOOR 3041AP2741G R
435300 GRILLE,REAR 1A00208H R
435301 GRILLE,DISCHARGE 3530A20007J R
435511 COVER ASSEMBLY,CONTROL(OUTDOOR) 3550AR2886C R
237204 PANEL,SIDE 3720AR7035C
435512 COVER ASSEMBLY,TOP(OUTDOOR) 3H03266H R
437210 PANEL ASSEMBLY,FRONT(SUB) 1A00197C R
447910 BARRIER ASSEMBLY,OUTDOOR 4791A30004H R
546810 MOTOR ASSEMBLY ,OUTDOOR 4681A10030C R
W 49810 SUPPORTER ASSEMBLY 4980A20001B
550140 DAMPER,COMPRESSOR 4H00982E R
552112 TUBE ASSEMBLY,CONDENSER(IN) 5211A25715A R
552113 TUBE ASSEMBLY,CONDENSER(OUT) 5211A25716A R
552114 TUBE ASSEMBLY,DISCHARGE (OUTDOOR) 5211A29916A R
552117 TUBE ASSEMBLY,SUCTION(OUTDOOR) 5211A29913A R
552203-1 VALVE,SERVICE 5220A20007A R
552203-2 VALVE,SERVICE 5220A20006A R
554031 CONDENSER ASSEMBLY,BENDING 5403A20022T R
554160 COMPRESSOR 2520UGKK2AA(GK120KAA,2EA) R
559010 FAN ASSEMBLY,PROPELLER 1A00195B R
56141 0 SOLENOID 6141A20018Z R
567502 OVERLOAD PROTECT 6750U-L035A R
649950 CASE ASSEMBLY,CONTROL(OUTDOOR) 4995A10112M R
W 6920 RELAY,CONTACT 6920AP3400A
W0CZZ-1 Capacitor,AL,Radial 3A00988B(35uF) R
W0CZZ-2 CAPACITOR,FILM,BOX 6120AR2194F(6+35uF) R
W4810 BRACKET 3A01934B
W4986 GASKET 4986U-L001G
26871 1 PCB ASSEMBLY, MAIN 6871A21318D R
LCU240CP / LC240CPO
LOCATION
No.
DESCRIPTION
Part No.
REMARKS
